18v pcb old High Frequency switching power supply EE EI EF series electronic Planar Transformers
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type On-board planar transformer Mounting Type Plug-in encapsulation Function Mobile phone adapter Supplier Type OEM/ODM Q @ Freq 180 MIN Application PV inverter,Energy storage transformers Rated Power 300w~3000W Operating Temperature -40°C~+125°C Inductance 200uH±5% Size / Dimension 43.5*40*33mm(1.71*1.57*1.30in) Number of Coils 14.5T Inductance – Connected In Parallel 300uH±5% DC Resistance (DCR) – Parallel 15mΩ MAX Shielding […]
Introduction
| Type | On-board planar transformer | Mounting Type | Plug-in encapsulation |
| Function | Mobile phone adapter | Supplier Type | OEM/ODM |
| Q @ Freq | 180 MIN | Application | PV inverter,Energy storage transformers |
| Rated Power | 300w~3000W | Operating Temperature | -40°C~+125°C |
| Inductance | 200uH±5% | Size / Dimension | 43.5*40*33mm(1.71*1.57*1.30in) |
| Number of Coils | 14.5T | Inductance - Connected In Parallel | 300uH±5% |
| DC Resistance (DCR) - Parallel | 15mΩ MAX | Shielding | Coil-Coil 100 MΩ Min |
| Material - Core | PQ40/40 | DC Resistance (DCR) | 180 MIN |
| Product Name | LT-HW65W-ATQ25 | Application | Secure Power Isolation and Step-Down smartphoneTransformer |
| Thermal conductivity of silica gel | 1.8 W/mk | Interlayer insulation | 2-1:1500Vdc |
| Certification | ISO9001 ISO14001 RoHS REACH | tube | WF CB-TT(L)TFS |
| High and low temperature impact test | 105±5% -40±5% | Common mode testing | -50mV ~ +30mV |
| Core shape | PQ type |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
