2+16G/4+32G RK3568 2GHz 4-Layer Embedded Board for Digital Signage Android11/Ubuntu20.04 4K LVDS Advertising Player Custom PCBA
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Number of Layers 4 Layer Type Multilayer pcb Board Thickness 1.6mm(0.06in) Board Size Max.880*580 Base Material FR4 Copper Thickness 1oz Min. Hole Size 4mil Min. Line Width 4mil Min. Line Spacing 6mil Surface Finishing HASL Main Control Processor RK3568 maximum frequency 2.0 GHZ Memory 2G / 4G / 8G DDR4 optional Flash Memory 16G to […]
Introduction
| Number of Layers | 4 Layer | Type | Multilayer pcb |
| Board Thickness | 1.6mm(0.06in) | Board Size | Max.880*580 |
| Base Material | FR4 | Copper Thickness | 1oz |
| Min. Hole Size | 4mil | Min. Line Width | 4mil |
| Min. Line Spacing | 6mil | Surface Finishing | HASL |
| Main Control Processor | RK3568 maximum frequency 2.0 GHZ | Memory | 2G / 4G / 8G DDR4 optional |
| Flash Memory | 16G to 64G optional | Video Output | support LVDS (dual 8,1920 * 1080), EDP (2560 * 1440), |
| Audio Output | stereo sound, support Dolby sound effects | Network | support 10MHZ/100MHZ/1000MHZ wired and 2.4G wireless WIFI |
| Operating System | ANDROID11, Ubuntu20.04, etc | PCB Size | 158mmX95mm |
| Power Supply Mode | DC12V / 3A input | USB Interface | USB 3.0 HOST / OTG |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
