4 Layer Double Sided PCB Manufacturing Express for IoT Device Smart Home Durable High Performance IoT PCBA Prototype
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Material FR-4 Functional Application Device Main Control, Data Processing Type electronic board Base Material FR-4 Board Thickness 1.6mm(0.06in) Copper Thickness 1 oz Min. Hole Size ≥0.3mm(≥0.01in) Min. Line Width ≥0.1mm(≥0in) Min. Line Spacing ≥0.1mm(≥0in) Surface Finishing ENIG Board Size 100mm*80mm(3.94in*3.15in) Layers 4 Layers Assembly Process SMT + THT Mixed Assembly(BGA MCU, Memory Chips, USB Interface) […]
Introduction
| Material | FR-4 | Functional Application | Device Main Control, Data Processing |
| Type | electronic board | Base Material | FR-4 |
| Board Thickness | 1.6mm(0.06in) | Copper Thickness | 1 oz |
| Min. Hole Size | ≥0.3mm(≥0.01in) | Min. Line Width | ≥0.1mm(≥0in) |
| Min. Line Spacing | ≥0.1mm(≥0in) | Surface Finishing | ENIG |
| Board Size | 100mm*80mm(3.94in*3.15in) | Layers | 4 Layers |
| Assembly Process | SMT + THT Mixed Assembly(BGA MCU, Memory Chips, USB Interface) | Certificate | ISO 9001/ISO 13485/TATF 16949 |
| Application | Embedded Linux Device/ IoT Terminal/Smart Device | Other Service | Conformal coating/ UV glue/Programming Test/DFM/FAE |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
