48hr Fast Turn High Frequency Double Sided PCB Custom Cost Effective Rogers PCBA for Consumer Electronics & RF
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Material Rogers (Genuine)/Taconic/ShengYi (High-Speed)/ITEQ Functional Application RF Microwave / 5G IoT / Antenna Prototyping Type High Frequency PCB / RF Circuit Board Base Material Rogers RO4350B / RO4003C Hybrid with High TG FR4 Board Thickness 0.508mm (20mil) / 0.762mm (30mil) / 1.524mm (60mil Copper Thickness 0.5oz (18um) / 1.0oz (35um) Min. Hole Size 0.15mm (Mechanical) […]
Introduction
| Material | Rogers (Genuine)/Taconic/ShengYi (High-Speed)/ITEQ | Functional Application | RF Microwave / 5G IoT / Antenna Prototyping |
| Type | High Frequency PCB / RF Circuit Board | Base Material | Rogers RO4350B / RO4003C Hybrid with High TG FR4 |
| Board Thickness | 0.508mm (20mil) / 0.762mm (30mil) / 1.524mm (60mil | Copper Thickness | 0.5oz (18um) / 1.0oz (35um) |
| Min. Hole Size | 0.15mm (Mechanical) / 0.1mm (Laser Microvia) | Min. Line Width | 0.075mm (3mil) |
| Min. Line Spacing | 0.075mm (3mil) | Surface Finishing | ENIG (Immersion Gold) / Immersion Silver / OSP |
| Board Size | 2 Layers (Double-Sided High Frequency) | Impedance Control | ±5% High Precision (Polar SI9000 Verified) |
| Insertion Loss | Optimized for <0.5dB/inch at high frequencies | Plasma Treatment | Available for PTFE/Rogers Materials |
| Inspection Suite | 100% TDR (Time Domain Reflectometry) & 100% E-test | SLA | 2h Technical EQ Response / 48-Hour Rapid Prototyping |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
