6 Layer HDI Drone PCB Prototype Second Order Precision Multilayer Board with High TG170 for Aerial Photography
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Material ShengYi (IT-180A) / Isola / Functional Application Aerial Photography Drone / FPV / Type High Density Interconnect (HDI) PCB Base Material High TG FR4 (TG170/180) Board Thickness 0.8mm / 1.0mm / 1.2mm Copper Thickness 1oz (35um) Min. Hole Size 0.075mm (3mil) Laser Microvia Min. Line Width 0.05mm (2mil) Min. Line Spacing 0.05mm (2mil) Surface […]
Introduction
| Material | ShengYi (IT-180A) / Isola / | Functional Application | Aerial Photography Drone / FPV / |
| Type | High Density Interconnect (HDI) PCB | Base Material | High TG FR4 (TG170/180) |
| Board Thickness | 0.8mm / 1.0mm / 1.2mm | Copper Thickness | 1oz (35um) |
| Min. Hole Size | 0.075mm (3mil) Laser Microvia | Min. Line Width | 0.05mm (2mil) |
| Min. Line Spacing | 0.05mm (2mil) | Surface Finishing | ENIG (Immersion Gold) / ENEPIG |
| Board Size | 6 Layers (Second-Order HDI) | Base Material TG | High TG 170°C (TG170) |
| Aspect Ratio | 12:1 | Min Drilling Hole Size | 0.3mm (12 mil) Mechanical Drill |
| Hole Wall Copper Thickness | 25um (1 mil) Average | Operating Temperature | -40°Cto +150°C |
| Withstanding Voltage | ≥1000V AC (Layer to Layer) | Thermal Conductivity | ≥2.0 W/m-K (with Metal Core) |
| Impedance Control Tolerance | ±10% Controlled Impedance | Flammability Rating | UL 94V-0 |
| Application Scenarios | EV Motor Controllers Industrial Drives High-Power Inverters |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
