8 Layers High Tg HDI Gold Impregnated Rogers High Frequency HDI PCB
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type High Frequency PCB Base Material FR4 ,Any specialized material as per your choice Board Thickness 0.3 mm- 4 mm(0.01in-0.16in) Copper Thickness 0.3- 6 OZ Min. Hole Size 0.2 mm(0.01in) Min. Line Width 0.1 mm(0in) Min. Line Spacing 0.1 mm(0in) Surface Finishing Lead/ Lead-free HASL, ENIG, Silver, OSP Board Size OEM Item High Tg HDI […]
Introduction
| Type | High Frequency PCB | Base Material | FR4 ,Any specialized material as per your choice |
| Board Thickness | 0.3 mm- 4 mm(0.01in-0.16in) | Copper Thickness | 0.3- 6 OZ |
| Min. Hole Size | 0.2 mm(0.01in) | Min. Line Width | 0.1 mm(0in) |
| Min. Line Spacing | 0.1 mm(0in) | Surface Finishing | Lead/ Lead-free HASL, ENIG, Silver, OSP |
| Board Size | OEM | Item | High Tg HDI Gold Impregnated Rogers High Frequency HDI PCB |
| Maximum Processing Area | 680 x 1000MM | Number of Layer | 1- 20 Layer |
| Silkscreen color | Black, White, Red, Green | MOQ | 1 PC |
| Finished Board | Thickness: ≤ 1.0MM, Tolerance:±0.1MM | Twisting and Bending | ≤ 0.75%, Min: 0.5% |
| Range of TG | 130 - 215 ℃ | Service | One-Stop OEM Service |
| Certificate | ISO9001.ROSH.UL |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
