Aluminum LED PCB Circuit Board Custom PCBA Assembly Manufacturing 1oz Copper Thickness HSAL ENIG OSP Surface Finish 1.6mm
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type Aluminum PCB Base Material aluminum Board Thickness 1.6mm(0.06in) Copper Thickness 1oz Min. Hole Size 0.2mm(0.01in) Min. Line Width 3mil Min. Line Spacing 3mil Surface Finishing HSAL ENIG OSP Board Size optional Impedence Control Tolerance ±5% Board thickness tolerance +/-10% Plugging Vias Capability 0.2-0.8mm Testing Service E-test PCB Standard IPC-A-610 D Hole tolerance PTH: +/-3mil […]
Introduction
| Type | Aluminum PCB | Base Material | aluminum |
| Board Thickness | 1.6mm(0.06in) | Copper Thickness | 1oz |
| Min. Hole Size | 0.2mm(0.01in) | Min. Line Width | 3mil |
| Min. Line Spacing | 3mil | Surface Finishing | HSAL ENIG OSP |
| Board Size | optional | Impedence Control Tolerance | ±5% |
| Board thickness tolerance | +/-10% | Plugging Vias Capability | 0.2-0.8mm |
| Testing Service | E-test | PCB Standard | IPC-A-610 D |
| Hole tolerance | PTH: +/-3mil NPTH: +/-2mil | Max panel size | ≤2sidesPCB: 600*1500mm Multilayer PCB: 500*1200mm |
| Service | One-stop Service | Inner package | Vacuum package |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
