Aluminum LED PCB Circuit Board Custom PCBA Board Assembly Manufacturing RGB PCB
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Material FR-4, FR4 CEM1 CEM3 Hight TG Functional Application Optional Type Pcb Board Base Material Aluminum Base Board Thickness 1.6mm(0.06in) Copper Thickness 1.6OZ Min. Hole Size 0.2mm(0.01in) Min. Line Width 4mil Min. Line Spacing 4mil Surface Finishing HASL Board Size custom made Impedence Control Tolerance ±5% Board thickness tolerance +/-10% Plugging Vias Capability 0.2-0.8mm Testing […]
Introduction
| Material | FR-4, FR4 CEM1 CEM3 Hight TG | Functional Application | Optional |
| Type | Pcb Board | Base Material | Aluminum Base |
| Board Thickness | 1.6mm(0.06in) | Copper Thickness | 1.6OZ |
| Min. Hole Size | 0.2mm(0.01in) | Min. Line Width | 4mil |
| Min. Line Spacing | 4mil | Surface Finishing | HASL |
| Board Size | custom made | Impedence Control Tolerance | ±5% |
| Board thickness tolerance | +/-10% | Plugging Vias Capability | 0.2-0.8mm |
| Testing Service | E-test | PCB Standard | IPC-A-610 D |
| Hole tolerance | PTH: +/-3mil NPTH: +/-2mil | Max panel size | ≤2sidesPCB: 600*1500mm Multilayer PCB: 500*1200mm |
| Service | One-stop Service | Shipping | DHL UPS TNT Fedex |
| Inner package | Vacuum package |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
