Automotive 6-Layer Rigid-Flex PCB Board Manufacturer Custom High Precision Multilayer Quick Turn Prototype for Industrial
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Material FR-4 Functional Application Automotive Type Pcb Board Base Material Rogers R04350B/PTFE/High TG FR4 Board Thickness Customizable Copper Thickness Customizable Min. Hole Size Customizable Min. Line Width Customizable Min. Line Spacing Customizable Surface Finishing Customizable Board Size Customizable Layer Count Up to 40 layers Surface Roughness Control HVLP copper: Ra ≤ 0.5um (for minimal signal […]
Introduction
| Material | FR-4 | Functional Application | Automotive |
| Type | Pcb Board | Base Material | Rogers R04350B/PTFE/High TG FR4 |
| Board Thickness | Customizable | Copper Thickness | Customizable |
| Min. Hole Size | Customizable | Min. Line Width | Customizable |
| Min. Line Spacing | Customizable | Surface Finishing | Customizable |
| Board Size | Customizable | Layer Count | Up to 40 layers |
| Surface Roughness Control | HVLP copper: Ra ≤ 0.5um (for minimal signal loss) | Dk / Df | Dk 3.0-10.2 / Df 0.001-0.020 @10GHz (material dependent) |
| Impedance Tolerance | ±5% (TDR tested, 50Ω/100Ω) | Back Drilling Depth Control | ±0.05 mm precision |
| HDI Technology | Laser drilled blind/buried vias, 0.1 mm hole | Via-in-Pad | Resin plugging & copper plated over |
| ENIG Thickness | Au 2-4u" / Ni 120-200u" | Copper Foil Type | HVLP / RTF / VLP (for low loss) |
| Certifications | UL, RoHS, REACH, ISO9001, IATF16949 |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
