Automotive EPS PCB Custom Printed Circuit Board Halogen Free FR4 PCB PCBA for Electric Power Steering Gear Unit
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type Multilayer pcb Board Thickness 0.2 mm – 5.0 mm(0.01in-0.20in) Board Size Max. : 800 mm X 800 mm Base Material FR4, PTFE, PI, Rogers, CEM-3 Copper Thickness 0.5 oz – 100 oz Min. Hole Size Laser 0.10 mm Mech 0.20 mm Min. Line Width 3 mil (0.075 mm) Min. Line Spacing 3 mil (0.075 […]
Introduction
| Type | Multilayer pcb | Board Thickness | 0.2 mm - 5.0 mm(0.01in-0.20in) |
| Board Size | Max. : 800 mm X 800 mm | Base Material | FR4, PTFE, PI, Rogers, CEM-3 |
| Copper Thickness | 0.5 oz - 100 oz | Min. Hole Size | Laser 0.10 mm Mech 0.20 mm |
| Min. Line Width | 3 mil (0.075 mm) | Min. Line Spacing | 3 mil (0.075 mm) |
| Surface Finishing | ENIG, HASL,OSP, Carbon Ink, Immersion Ag | Product name | Power Steering Gear Printed Circuit Board |
| Application | Automotive Electronics | Certificate | ISO9001, CE/RoHS, IATF16949, UL, |
| Solder Mask Color | Green, Blue, Black, Red, Purple, White | Layer | 1-32 layers |
| PCB Assembly process | SMT, DIP soldering | One-Stop Service | PCB Layout PCB Fabrication PCBA Assembly |
| Testing | 100% ICT Testing and Functional Testing | On-Time Delivery Rate | 96.5% in 2024 |
| Qualification Rate | 98.2% in 2024 |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
