AX7Z100B V3.0 FPGA Development Board with AMD Xilinx Zynq 7000 ARM XC7Z100 2GB DDR3 8GB EMMC PCIe SFP HDM
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Embedded Yes, FPGA / CPLD Operating System Linux Board Type Evaluation Platform Communication Interface HDMI, SPI, uart, USB Mounting Type PCB Type Development Board Description ALINX AX7Z100B FPGA Development Board FPGA Chip XC7Z100-2FFG900I DDR3 2GB DDR3,32bit Bus, Data Rate 1066Mbps QSPI FLASH 512Mbit, Used as FPGA User Data Storage eMMC FLASH 8GB,Used as a Large-Capacity […]
Introduction
| Embedded | Yes, FPGA / CPLD | Operating System | Linux |
| Board Type | Evaluation Platform | Communication Interface | HDMI, SPI, uart, USB |
| Mounting Type | PCB | Type | Development Board |
| Description | ALINX AX7Z100B FPGA Development Board | FPGA Chip | XC7Z100-2FFG900I |
| DDR3 | 2GB DDR3,32bit Bus, Data Rate 1066Mbps | QSPI FLASH | 512Mbit, Used as FPGA User Data Storage |
| eMMC FLASH | 8GB,Used as a Large-Capacity Storage Device in the ZYNQ System | SFP Interface x 4 | Each Channel is up to 10.3125Gb/s |
| Ethernet Interface | Two 10/100M/1000M with RJ-45 Interfaces for Data Exchange | USB 2.0 x 4 | Used for Connect USB Peripherals such as Mouse,Keyboard and U Disk |
| USB Uart | Used for Serial Communication with PC or External Devices | Crystal Oscillator | 33.333 Mhz; 125 Mhz ; 150 Mhz |
| 40-Pin Expansion Ports | Connect with Various ALINX Modules |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
