Blue Soldermask FR4 Rigid PCB Board for Fan Driver Display
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type rigid pcb Base Material FR-4 KB Board Thickness 1.0MM(0.04in) Board Size 78*78MM(3.07*3.07in) Copper Thickness 1OZ Min. Hole Size 0.5MM(0.02in) Min. Line Width 0.2MM(0.01in) Min. Line Spacing 0.2MM(0.01in) Surface Finishing HASL Lead Free Solder mask Ink Color GREEN shape CUSTOMIZED Application Panel Light, Spot light, Material: CEM-1 KB Board thickness: 1.0mm Copper foil thickness: 1oz […]
Introduction
| Type | rigid pcb | Base Material | FR-4 KB |
| Board Thickness | 1.0MM(0.04in) | Board Size | 78*78MM(3.07*3.07in) |
| Copper Thickness | 1OZ | Min. Hole Size | 0.5MM(0.02in) |
| Min. Line Width | 0.2MM(0.01in) | Min. Line Spacing | 0.2MM(0.01in) |
| Surface Finishing | HASL Lead Free | Solder mask Ink Color | GREEN |
| shape | CUSTOMIZED | Application | Panel Light, Spot light, |
| Material: | CEM-1 KB | Board thickness: | 1.0mm |
| Copper foil thickness: | 1oz | Board Size: | 286*286mm |
| Surface treatment: | HASL Lead Free | number of layers: | Single layer |
| Legend: | Silkprinting white |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
