Circuit Board Custom PCB Assembly Manufacture Flat Cable Printed Flexible PCB FPC Ultra Thin Flexible PCB
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type FPC Base Material FR-4/CEM-1/CEM-3/Polyimild/PTFE/Rogers Board Thickness 0.2-6mm(0.01-0.24in) Board Size Custom Copper Thickness 0.4-2mil(10-50um) Min. Hole Size 0.1mm(4mil)for HDI / 0.15mm(6mil) Min. Line Width 0.075mm/0.075mm(3mil/3mil) Min. Line Spacing 0.003'' Surface Finishing HASL/OSP/Ag/ENIG/ENEPIG/Immersion silver/Tin Non disclosure agreement(NDA) YES DFM and FAE service YES Lead Free Technology YES Free Service Optimize BOM to Reduce Pcb Assembly Costs […]
Introduction
| Type | FPC | Base Material | FR-4/CEM-1/CEM-3/Polyimild/PTFE/Rogers |
| Board Thickness | 0.2-6mm(0.01-0.24in) | Board Size | Custom |
| Copper Thickness | 0.4-2mil(10-50um) | Min. Hole Size | 0.1mm(4mil)for HDI / 0.15mm(6mil) |
| Min. Line Width | 0.075mm/0.075mm(3mil/3mil) | Min. Line Spacing | 0.003'' |
| Surface Finishing | HASL/OSP/Ag/ENIG/ENEPIG/Immersion silver/Tin | Non disclosure agreement(NDA) | YES |
| DFM and FAE service | YES | Lead Free Technology | YES |
| Free Service | Optimize BOM to Reduce Pcb Assembly Costs | FPC Thickness | 0.08-0.30mm |
| Certificates | CE ROHS ISO9001 | Hole Tolerance | NTPH: 0.05 |
| PCB Standard | IPC-A-610 E | Layer | 1-32 Layer(flex Board) |
| Product name | Flexible Printed Circuit Board |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
