Custom 10-Layer High-Frequency PCB Circuit Board Fast Turn 5G Telecom RF Systems ENIG Surface 1.8mm
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Number of Layers 10-Layer Solder Mask Green Type Multilayer pcb Board Thickness 1.8mm(0.07in) Board Size custom Base Material Rogers / Taconic / Arlon / PTFE / FR4 High TG Copper Thickness 1OZ Min. Hole Size 0.3mm(0.01in) Min. Line Width 0.35mm(0.01in) Min. Line Spacing 0.2mm(0.01in) Surface Finishing ENIG (Immersion Gold), Immersion Silver, HASL Layer Count 10 […]
Introduction
| Number of Layers | 10-Layer | Solder Mask | Green |
| Type | Multilayer pcb | Board Thickness | 1.8mm(0.07in) |
| Board Size | custom | Base Material | Rogers / Taconic / Arlon / PTFE / FR4 High TG |
| Copper Thickness | 1OZ | Min. Hole Size | 0.3mm(0.01in) |
| Min. Line Width | 0.35mm(0.01in) | Min. Line Spacing | 0.2mm(0.01in) |
| Surface Finishing | ENIG (Immersion Gold), Immersion Silver, HASL | Layer Count | 10 layers |
| Surface Roughness Control | HVLP copper Ra ≤ 0.5um (for minimal signal loss) | Dk / Df | Dk 3.0-10.2 / Df 0.001-0.020 @10GHz (material dependent) |
| Impedance Tolerance | ±5% (TDR tested, 50Ω/100Ω) | Back Drilling Depth Control | ±0.05 mm precision |
| HDI Technology | Laser drilled blind/buried vias, 0.1 mm hole | Via-in-Pad | Resin plugging & copper plated over |
| ENIG Thickness | Au 2-4u" / Ni 120-200u" | Copper Foil Type | HVLP / RTF / VLP (for low loss) |
| Certifications | UL, RoHS, REACH, ISO9001, IATF16949 |
