Custom High Quality HDI for PCB Assembly Fabrication PCBA Prototype Manufacturing Services RoHS Certification Multiple Surface
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type HDI Base Material FR4,FR1,CEM3,Aluminum,Ceramic Board Thickness 0.5~3.2mm(0.02~0.13in) Board Size OEM Copper Thickness 1oz~4oz Min. Hole Size 0.15mm(0.01in) Min. Line Width 0.08mm(0in) Min. Line Spacing 0.08mm(0in) Surface Finishing HASL,Lead Free HASL, OSP,ENIG,Gold plating PCB max. Panel Size 541*647mm(Special can do to 950mm) Finish Hole Size PTH +/-0.003'' ,NPTH +/-0.002" Hole Position Accuracy +/-0.003 Aspect Ratio […]
Introduction
| Type | HDI | Base Material | FR4,FR1,CEM3,Aluminum,Ceramic |
| Board Thickness | 0.5~3.2mm(0.02~0.13in) | Board Size | OEM |
| Copper Thickness | 1oz~4oz | Min. Hole Size | 0.15mm(0.01in) |
| Min. Line Width | 0.08mm(0in) | Min. Line Spacing | 0.08mm(0in) |
| Surface Finishing | HASL,Lead Free HASL, OSP,ENIG,Gold plating | PCB max. Panel Size | 541*647mm(Special can do to 950mm) |
| Finish Hole Size | PTH +/-0.003'' ,NPTH +/-0.002" | Hole Position Accuracy | +/-0.003 |
| Aspect Ratio | Min 1:8 | Hardness of resist ink | ≥6H |
| Copper foil peel off endurance | 1.4N/mm | Flame resistance | 94V-0 |
| Impedance control | ±5% | PCB Item | Aluminium LED PCB |
| PCB Certificate | RoSH, TS certificate |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
