Custom High Thermal Conductivity FR4 Aluminum PCB Circuit Board Assembly Service Manufacturer Multilayer SMT High Precision PCB
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type Aluminum PCB Base Material Aluminum/FR4 Board Thickness 1.6mm(0.06in) Copper Thickness 1oz Min. Hole Size 0.1mm(0in) Min. Line Width 0.1mm(0in) Min. Line Spacing 0.1mm(0in) Surface Finishing HASL Board Size Optional Thermal conductivity High Thermal Conductivity (1.0W/m.K, 1.5W/m.K, 2.0W/m.K, etc.) Insulation layer High Dielectric Strength Insulation Layer (e.g., 3KV) Copper foil thickness 1oz/2oz/3oz Copper Foil Aluminum […]
Introduction
| Type | Aluminum PCB | Base Material | Aluminum/FR4 |
| Board Thickness | 1.6mm(0.06in) | Copper Thickness | 1oz |
| Min. Hole Size | 0.1mm(0in) | Min. Line Width | 0.1mm(0in) |
| Min. Line Spacing | 0.1mm(0in) | Surface Finishing | HASL |
| Board Size | Optional | Thermal conductivity | High Thermal Conductivity (1.0W/m.K, 1.5W/m.K, 2.0W/m.K, etc.) |
| Insulation layer | High Dielectric Strength Insulation Layer (e.g., 3KV) | Copper foil thickness | 1oz/2oz/3oz Copper Foil |
| Aluminum Base Thickness | 1.0mm/1.5mm/2.0mm | Flame retardant grade | FR-4 Flame Retainer Aluminum Cladd Laminated |
| Surface treatment | HASL Lead Free/ENIG (Immersion Gold)/OSP Surface Finish | Precision and Craftsmanship | High Precision Routing/CNC Drilling |
| Testing Service | FCT/E-Test/BGA/Fly-probe/AOI/XRay/100%function Testing | Custom Service | Pcb Circuit/SIZE/Custom Logo/Color |
| PCBA service | SMD SMT DIP Component/Turnkey Assembly PCBA Service |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
