Custom PCB 28x28mm 350W RGBW RGBCW COB LED Module 2700K 6500K CRI 95 3 Year Warranty for High end Commercial Cinema Studio
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Input Voltage(V) DC 36 V Power 350W Color Temperature(CCT) 6000K (Daylight Alert) Working Hours 50000 Color Rendering Index(Ra) 95 Support Dimmer Yes Emitting Color Tri-Color(Red-Blue-Green) Warranty(Year) 3-Year Chip Material Ingan Lighting solutions service Lighting And Circuitry Design, Auto Cad Layout, Project Installation Type Cob Led Luminous Efficacy(lm/w) 120 Color Temperature 2700-7000K Luminous Flux(lm) 30000-40000LM Luminous […]
Introduction
| Input Voltage(V) | DC 36 V | Power | 350W |
| Color Temperature(CCT) | 6000K (Daylight Alert) | Working Hours | 50000 |
| Color Rendering Index(Ra) | 95 | Support Dimmer | Yes |
| Emitting Color | Tri-Color(Red-Blue-Green) | Warranty(Year) | 3-Year |
| Chip Material | Ingan | Lighting solutions service | Lighting And Circuitry Design, Auto Cad Layout, Project Installation |
| Type | Cob Led | Luminous Efficacy(lm/w) | 120 |
| Color Temperature | 2700-7000K | Luminous Flux(lm) | 30000-40000LM |
| Luminous Intensity | 120-130lm/w | Operating Temperature(℃) | -40 - 85 |
| Optical Attenuation(%) | 0.03 | Power Dissipation | 0.01 |
| Product Weight（kg） | 0.02 | Storage Temperature(℃) | -40 - 100 |
| Viewing Angle(°) | 120 | Product name | RGBCW COB LED Chip |
| Watt | 350W | Size | 28*28mm |
| Les | 24mm | Voltage | 34-40V |
| Current | R/G/B:1300mAW/C:2800mA | Lumen | R1800-2000LM G4000-4200LM B1000-1200LM WW8000-9000LM CW10000-11000LM |
| CRI | 95 | CCT | RGB+2700K+6000K |
| Color | RGBCW Five in One |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
