Customized Hybrid Lamination PCB With Gerber RO4350B High TG FR4 RF Power Amplifier High Frequency Printed Circuit Board
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type Hybrid Lamination PCB Base Material FR4, Rogers, Taconic, PTFE, PPO, Metal Core Board Thickness 0.2mm-5.0mm(0.01in-0.20in) Copper Thickness 0.5oz-20oz Min. Hole Size 0.075mm /3mil Min. Line Width 0.075mm /3mil Min. Line Spacing 0.075mm /3mil Surface Finishing ENIG, HASL, OSP, Immersion Tin, ENEPIG Board Size Max.600×510 mm PCB Type Hybrid Lamination Printed Circuit Board Application RF […]
Introduction
| Type | Hybrid Lamination PCB | Base Material | FR4, Rogers, Taconic, PTFE, PPO, Metal Core |
| Board Thickness | 0.2mm-5.0mm(0.01in-0.20in) | Copper Thickness | 0.5oz-20oz |
| Min. Hole Size | 0.075mm /3mil | Min. Line Width | 0.075mm /3mil |
| Min. Line Spacing | 0.075mm /3mil | Surface Finishing | ENIG, HASL, OSP, Immersion Tin, ENEPIG |
| Board Size | Max.600x510 mm | PCB Type | Hybrid Lamination Printed Circuit Board |
| Application | RF Power Amplifier Electronics | Certificate | ISO14001, ISO45001, IATF16949, UL, ISO13485 |
| Solder Mask Color | Green, White, Blue, Black, Red, Purple | Layer | 1-32 layers |
| Finish Hole Tolerance (PTH) | ±0.05 mm | Finish Hole Tolerance (NPTH) | ±0.025 mm |
| One-Stop Service | Hybrid Lamination PCB Design Manufacturing and PCBA Assembly | PCBA service | SMD SMT DIP Component Assembly |
| Production Files | Gerber, BOM, Pick and Place |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
