Directional Wideband Broadband UWB WiFi Antenna Board for Communication 800M 6G 28 Degree Standard Thread Size
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type Log-Periodic Dipole Array (LPDA) Antenna Gain 6.5dBi (Typical) Number Of Bands Ultra-Wideband (UWB) Terminals Gold-Plated Dipoles Installation PCB Solder / Right Angle SMA Connector Type SMA Female (SMA-K) Return Loss ≤-10dB Height 185mm (Board Length) Ingress Protection IP00 (Laboratory Internal) Polarization Linear Polarization Maximum input power 5W (Testing Grade) Antenna Frequency 800-6000MHz Application EMI/EMC […]
Introduction
| Type | Log-Periodic Dipole Array (LPDA) | Antenna Gain | 6.5dBi (Typical) |
| Number Of Bands | Ultra-Wideband (UWB) | Terminals | Gold-Plated Dipoles |
| Installation | PCB Solder / Right Angle SMA | Connector Type | SMA Female (SMA-K) |
| Return Loss | ≤-10dB | Height | 185mm (Board Length) |
| Ingress Protection | IP00 (Laboratory Internal) | Polarization | Linear Polarization |
| Maximum input power | 5W (Testing Grade) | Antenna Frequency | 800-6000MHz |
| Application | EMI/EMC Pre-compliance Testing | Shape | Aerodynamic Triangular Design |
| Processing | Immersion Gold (ENIG) Finish | Polarization | Vertical Polarization |
| Impedance | 50 Ohm | VSWR | ≤1.5 (Typical) |
| Connector type | SMA / N / TNC / BNC or Customized | Beamwidth | 28 Degree |
| Material | High-Quality FR-4 PCB | Cable type | 1M RG174 / Customized |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
