Double-Sided Rapid Prototyping PCB PCBA Service for Consumer Electronics Wearable Device OEM ODM
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Material FR-4 Functional Application Industrial Control Type electronic board Base Material FR-4 Board Thickness 1.6mm(0.06in) Copper Thickness 1 oz Min. Hole Size ≥0.3mm(≥0.01in) Min. Line Width 0.15mm(0.01in) Min. Line Spacing 0.15mm(0.01in) Surface Finishing ENIG/HASL Board Size 350mm*120mm(13.78in*4.72in) Layers 2 Layers Assembly Process SMT+DIP Application Smart Building / HVAC Control Unit/Security Equipment/Charging Pile Solder Paste Process […]
Introduction
| Material | FR-4 | Functional Application | Industrial Control |
| Type | electronic board | Base Material | FR-4 |
| Board Thickness | 1.6mm(0.06in) | Copper Thickness | 1 oz |
| Min. Hole Size | ≥0.3mm(≥0.01in) | Min. Line Width | 0.15mm(0.01in) |
| Min. Line Spacing | 0.15mm(0.01in) | Surface Finishing | ENIG/HASL |
| Board Size | 350mm*120mm(13.78in*4.72in) | Layers | 2 Layers |
| Assembly Process | SMT+DIP | Application | Smart Building / HVAC Control Unit/Security Equipment/Charging Pile |
| Solder Paste Process | Lead-Free Solder Paste, Hot Air Reflow Soldering | Welding Process | Wave Soldering |
| Cleaning Process | In-line Cleaning to Remove Solder Flux Residue | Certificate | ISO 9001/ISO 13485/TATF 16949 |
| Other Service | Conformal coating/ UV glue/Programming Test/DFM/FAE |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
