EGS002 Pure Sine Wave Inverter Driver Board EG8010 + IR2110 Driver Module with LCD Display Support
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Main Purpose DC-AC Inverter, Solar System, UPS, Wind Power Embedded Yes (EG8010 is an ASIC) Board Type Evaluation Board Type Development Board Core Processor EG8010 Interface 17-pin Header Description EGS002 Pure Sine Wave Inverter Driver with LCD Series EG Inverter Series Package Module Function Pure Sine Wave Generation, SPWM Control Utilized IC / Part EG8010 […]
Introduction
| Main Purpose | DC-AC Inverter, Solar System, UPS, Wind Power | Embedded | Yes (EG8010 is an ASIC) |
| Board Type | Evaluation Board | Type | Development Board |
| Core Processor | EG8010 | Interface | 17-pin Header |
| Description | EGS002 Pure Sine Wave Inverter Driver with LCD | Series | EG Inverter Series |
| Package | Module | Function | Pure Sine Wave Generation, SPWM Control |
| Utilized IC / Part | EG8010 + IR2110 | Number of Bits | 8-bit |
| Sampling Rate (Per Second) | 20KHz (SPWM Carrier Frequency) | Data Interface | UART |
| Input Range | 12V to 15V | Output Type | 50Hz |
| Max Output Power x Channels @ Load | N/A | Voltage - Supply | 5V (Logic) |
| Output Waveform | Pure Sine Wave | Protection Features | Under Voltage, Over Current, Overheat |
| Display Support | LCD12806 |
