ER28 High Frequency Ferrite Core Transformer Custom 12-48V Output for Power Supply LED Lighting SMPS Flyback Transformer
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type Power Transformer Input Voltage 110 V, 120 V, 220 V, 230 V Output Voltage 5 V, 12 V, 24 V, 9 V Frequency 50kHz-200kHz Phase Single Coil Number Autotransformer Winding Material Copper Material Aluminum, Mn-Zn Ferrite Core, Copper application Electronic Toplogy Buck, Flyback, Forward Coil Structure Toroidal Shape Rectangle Mounting Type PCB through-hole mounting, […]
Introduction
| Type | Power Transformer | Input Voltage | 110 V, 120 V, 220 V, 230 V |
| Output Voltage | 5 V, 12 V, 24 V, 9 V | Frequency | 50kHz-200kHz |
| Phase | Single | Coil Number | Autotransformer |
| Winding Material | Copper | Material | Aluminum, Mn-Zn Ferrite Core, Copper |
| application | Electronic | Toplogy | Buck, Flyback, Forward |
| Coil Structure | Toroidal | Shape | Rectangle |
| Mounting Type | PCB through-hole mounting, easy for soldering on circuit boards | Winding Material | High-purity copper wire, low resistance & high efficiency |
| Core Material | Ferrite core, excellent high-frequency magnetic performance | Isolation Type | Isolation transformer, safe electrical isolation for circuits |
| Operating Frequency | High frequency (1kHz-500kHz), ideal for switching power supplies | Certification | RoHS compliant, meets EU environmental & safety standards |
| Customization | Support ODM/OEM, customizable turns ratio & voltage specs | Package Type | ER28 bobbin package, compact size for space-saving design |
| Insulation Grade | Class B insulation, reliable for long-term stable operation | Application | For Notebook power supply, LED driver, industrial power supply |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
