Gold Finger PCBA Assembly Service for Graphics Card Motherboard Impedance Control High Performance Electronic PCBA
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Material FR-4 Functional Application Industrial Wireless Communication/Bluetooth/Wi-Fi Type electronic board Base Material FR-4 Board Thickness 1.2-1.6mm(0.05-0.06in) Copper Thickness 1 oz Min. Hole Size ≥0.15mm(≥0.01in) Min. Line Width ≥0.08mm(≥0in) Min. Line Spacing ≥0.08mm(≥0in) Surface Finishing ENIG Board Size 150mm*100mm(5.91in*3.94in) Layers 4 Layers Certificate ISO 9001/ISO 13485/TATF 16949 Panelization 2-Up Panel Application IoT Sensor/Vehicle/Security Equipment Assembly Process […]
Introduction
| Material | FR-4 | Functional Application | Industrial Wireless Communication/Bluetooth/Wi-Fi |
| Type | electronic board | Base Material | FR-4 |
| Board Thickness | 1.2-1.6mm(0.05-0.06in) | Copper Thickness | 1 oz |
| Min. Hole Size | ≥0.15mm(≥0.01in) | Min. Line Width | ≥0.08mm(≥0in) |
| Min. Line Spacing | ≥0.08mm(≥0in) | Surface Finishing | ENIG |
| Board Size | 150mm*100mm(5.91in*3.94in) | Layers | 4 Layers |
| Certificate | ISO 9001/ISO 13485/TATF 16949 | Panelization | 2-Up Panel |
| Application | IoT Sensor/Vehicle/Security Equipment | Assembly Process | Full SMT Precision Assembly (QFN, 0402 Components) |
| Other Service | Conformal coating/ UV glue/Programming Test/DFM/FAE |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
