HDI PCB Manufacturer OEM Multilayer Circuit Boards Prototyping Service
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type hdi pcb Base Material According to demand Board Thickness 0.3-4.0mm(0.01-0.16in) Copper Thickness 1-10 Oz Min. Hole Size 0.10mm (Mechanical) 0.07mm (Blind) 0.15mm (Buried) Min. Line Width Inner Layer: 1.5mil Outer Layer: 2.0mil Min. Line Spacing Inner Layer: 1.5mil Outer Layer: 2.0mil Surface Finishing Immersion Gold ,HASL, OSP, Immersion Tin Board Size OEM Item Wonderful […]
Introduction
| Type | hdi pcb | Base Material | According to demand |
| Board Thickness | 0.3-4.0mm(0.01-0.16in) | Copper Thickness | 1-10 Oz |
| Min. Hole Size | 0.10mm (Mechanical) 0.07mm (Blind) 0.15mm (Buried) | Min. Line Width | Inner Layer: 1.5mil Outer Layer: 2.0mil |
| Min. Line Spacing | Inner Layer: 1.5mil Outer Layer: 2.0mil | Surface Finishing | Immersion Gold ,HASL, OSP, Immersion Tin |
| Board Size | OEM | Item | Wonderful HDI PCB Factory |
| Maximum Processing Area | 680 x 1000MM | Number of Layer | 1- 28 Layer |
| Silkscreen Color | Black, White, Red, Green | MOQ | 1 PC |
| Finished Board | Thickness ≤ 1.0MM, Tolerance:±0.1MM | Twisting and Bending | ≤ 0.75%, Min: 0.5% |
| Range of TG | 130 - 215 ℃ | Service | High-Order HDI Manufacturing Capability |
| Certificate | ISO9001.ROSH.UL,IATF 16949,ISO 50001 |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
