Heltec BMS with Balance 2S 3S 4S 15A 20A 40A 35A 50A 80A 120A 160A 180A 200A 330A 380A NCM LFP Lithium Battery Protection Board
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Material FR-4 Functional Application Battery Protection, Battery balancing maintenance Type Pcb Board Base Material PCB Board Thickness – Copper Thickness – Min. Hole Size – Min. Line Width – Min. Line Spacing – Surface Finishing – Board Size Determined by current and number of battery string Number of battery strings 2S,3S,4S Current that the shield […]
Introduction
| Material | FR-4 | Functional Application | Battery Protection, Battery balancing maintenance |
| Type | Pcb Board | Base Material | PCB |
| Board Thickness | - | Copper Thickness | - |
| Min. Hole Size | - | Min. Line Width | - |
| Min. Line Spacing | - | Surface Finishing | - |
| Board Size | Determined by current and number of battery string | Number of battery strings | 2S,3S,4S |
| Current that the shield can withstand | 15A 20A 40A 35A 50A 80A 120A 160A 180A 200A 330A 380A | Battery type | Ternary lithium / lithium iron phosphate(NCM/LFP) |
| Protection release condition | Break short circuit | Wiring method | same port or split port |
| Current Consumption | MIN: 0.3μA; MAX: 100μA | Charger selection | Voltage = Strings*4.2V±0.05V |
| Balance start delay time | 1.6s (MAX) | Battery balance release voltage | 4.21V±0.035V |
| Battery balancing current | 100mA±5mA |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
