High Density FR4 FPV Drones PCB 6 Layer HDI Prototype Thermal Conductivity 2.0 W/m-K ENIG Surface Finishing for Drones Aerial
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Number of Layers 6-layer Solder Mask Green Type Multilayer pcb Board Thickness 2.0mm(0.08in) Board Size custom pcb Base Material FR4 Copper Thickness 20Z Min. Hole Size 0.1mm(0in) Min. Line Width 0.1mm(0in) Min. Line Spacing 0.1mm(0in) Surface Finishing ENIG (Immersion Gold), Immersion Silver, HASL Base Material TG High TG 170°C (TG170) Aspect Ratio 12:1 Min Drilling […]
Introduction
| Number of Layers | 6-layer | Solder Mask | Green |
| Type | Multilayer pcb | Board Thickness | 2.0mm(0.08in) |
| Board Size | custom pcb | Base Material | FR4 |
| Copper Thickness | 20Z | Min. Hole Size | 0.1mm(0in) |
| Min. Line Width | 0.1mm(0in) | Min. Line Spacing | 0.1mm(0in) |
| Surface Finishing | ENIG (Immersion Gold), Immersion Silver, HASL | Base Material TG | High TG 170°C (TG170) |
| Aspect Ratio | 12:1 | Min Drilling Hole Size | 0.3mm (12 mil) Mechanical Drill |
| Hole Wall Copper Thickness | 25um (1 mil) Average | Operating Temperature | -40°Cto +150°C |
| Withstanding Voltage | ≥1000V AC (Layer to Layer) | Thermal Conductivity | ≥2.0 W/m-K (with Metal Core) |
| Impedance Control Tolerance | ±10% Controlled Impedance | Flammability Rating | UL 94V-0 |
| Application Scenarios | EV Motor Controllers Industrial Drives High-Power Inverters |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
