Low Cost Double Sided FR4 PCB Small Batch Customization for Home Appliance Control PCBA Service Complex Biometric Sensor Board
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Material FR-4 Functional Application Industrial Vision Inspection/Camera Processing Type electronic board Base Material FR-4 Board Thickness 1.6mm(0.06in) Copper Thickness 1 oz Min. Hole Size ≥0.2mm(≥0.01in) Min. Line Width ≥0.08mm(≥0in) Min. Line Spacing ≥0.08mm(≥0in) Surface Finishing ENIG Board Size 150mm*100mm(5.91in*3.94in) Layers 4 Layers Certificate ISO 9001/ISO 13485/TATF 16949 Assembly Process Full SMT Precision Assembly Panelization 2-Up […]
Introduction
| Material | FR-4 | Functional Application | Industrial Vision Inspection/Camera Processing |
| Type | electronic board | Base Material | FR-4 |
| Board Thickness | 1.6mm(0.06in) | Copper Thickness | 1 oz |
| Min. Hole Size | ≥0.2mm(≥0.01in) | Min. Line Width | ≥0.08mm(≥0in) |
| Min. Line Spacing | ≥0.08mm(≥0in) | Surface Finishing | ENIG |
| Board Size | 150mm*100mm(5.91in*3.94in) | Layers | 4 Layers |
| Certificate | ISO 9001/ISO 13485/TATF 16949 | Assembly Process | Full SMT Precision Assembly |
| Panelization | 2-Up Symmetric Panel,V-Cut Depanelization | Application | Security Surveillance Camera/Industrial Vision Inspection Equipment |
| Other Service | Conformal coating/ UV glue/Programming Test/DFM/FAE |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
