Metal Core PCB MCPCB for High Power LED Lighting and Heat Dissipation
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type metal core pcb Base Material Copper Board Thickness 1.5mm(0.06in) Copper Thickness 1oz Min. Hole Size 0.1mm(0in) Min. Line Width 1mil Min. Line Spacing 1mil Surface Finishing HASL LF Board Size 10*10cm(3.94*3.94in) Board Dimension(CM) 10*10cm Number of Layers Single layer Panel Information Same Boards in Panel Planelize 3*3 Extra Rail No Fiducial Points No Finished […]
Introduction
| Type | metal core pcb | Base Material | Copper |
| Board Thickness | 1.5mm(0.06in) | Copper Thickness | 1oz |
| Min. Hole Size | 0.1mm(0in) | Min. Line Width | 1mil |
| Min. Line Spacing | 1mil | Surface Finishing | HASL LF |
| Board Size | 10*10cm(3.94*3.94in) | Board Dimension(CM) | 10*10cm |
| Number of Layers | Single layer | Panel Information | Same Boards in Panel |
| Planelize | 3*3 | Extra Rail | No |
| Fiducial Points | No | Finished Thickness (mm) | 1.8mm |
| Board Type | Car Boards | Outer Copper | 1oz |
| Inner Copper | 1oz |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
