Microwave RF Circuit Board Rogers RO4003C PCB Custom OEM Multilayer High Frequency Fabrication Turnkey Service
$1.88-5.99
/piece
Price varies depending on material, logo, quantity and customization requirements.
Quality You Can Trust
Flexible & Scalable Solutions
Customizable Product Options
Comprehensive Specifications
Your Reliable Business Partner
Category:
Ceramic Pcb
Introduction
| Type | High Frequency PCB | Base Material | Rogers (PTFE / Ceramic-filled / Hydrocarbon) |
| Board Thickness | 0.1mm - 3.2mm (Customizable) | Copper Thickness | 0.5oz-4oz (18μm-140μm), Customizable up to 6oz |
| Min. Hole Size | 0.1mm(Mechanical Drilling)/0.075mm(Laser Microvia) | Min. Line Width | 0.075mm (3mil), HDI down to 0.05mm (2mil) |
| Min. Line Spacing | 0.075mm (3mil), HDI down to 0.05mm (2mil) | Surface Finishing | ENIG / OSP / HASL / Hard Gold / ENEPIG |
| Board Size | OEM / ODM / Customized | Application | 5G / RF Microwave / Automotive Radar / Aerospace / Satellite |
| Rogers Material Series | RO4000 Series / RO3000 Series / RT/duroid Series | Frequency Range | Up to 77GHz / mmWave Compatible |
| Via Technology | Blind Via / Buried Via / Any-Layer HDI / Laser Microvia | Service Type | One-Stop Fabrication / Turnkey OEM / Quick Turn Prototype |
| DFM Support | Free DFM Check / 24H Engineering Feedback | Lead Time | Prototype 3-5 Days / Mass Production 7-15 Days |
| Quality Standard | IPC Class 3 / 100% E-Test / AOI Inspection | Hybrid Stack-up | Rogers + FR4 Hybrid / Mixed Dielectric |
| Sample Policy | Sample Available / MOQ 1 PCS / Low MOQ Accepted |
We are a professional manufacturer and supplier, dedicated to maintaining consistent quality and establishing long-term partnerships with clients worldwide.
Our mission is to provide high-quality products and reliable service. We are committed to offering the following advantages:
- Stable production system ensuring consistent quality, dependable supply, and standardized manufacturing management;
- Strict quality control covering material selection, processing, surface finishing, and final packaging;
- Variety of products and specifications to meet diverse project requirements and application scenarios;
- OEM & customization support based on drawings, samples, or specific technical requirements;
- Flexible packaging solutions to ensure safe handling and transportation of products;
- Continuous improvement in products and services to better support customers in different markets.
If you are interested in our products, please feel free to contact us. We look forward to establishing long-term and mutually beneficial cooperation with you.
