MIL DTL 38999 D38999 38999 Circular Connector Series I II III 2 5 6 10 13 55 Pin Mil Class Din D38999 24 D38999 26 DS38999 26
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type Circular Connector Rated Current 5A to 80A (Dependent on Pin Size 22D to 8) Rated Voltage 400V to 1000V AC rms (Sea Level) IP Level Ip67 Contact Material Gold-Plated Beryllium Copper Alloy Housing Material Aluminum Alloy Gender Male/Female Shape Round, Circular Number of Positions 3/4/5/6/8/10/12/13/19/22/37/66/79 Pin Operating Temperature -65 C/deg to +200 C/deg Shielding […]
Introduction
| Type | Circular Connector | Rated Current | 5A to 80A (Dependent on Pin Size 22D to 8) |
| Rated Voltage | 400V to 1000V AC rms (Sea Level) | IP Level | Ip67 |
| Contact Material | Gold-Plated Beryllium Copper Alloy | Housing Material | Aluminum Alloy |
| Gender | Male/Female | Shape | Round, Circular |
| Number of Positions | 3/4/5/6/8/10/12/13/19/22/37/66/79 Pin | Operating Temperature | -65 C/deg to +200 C/deg |
| Shielding Effectiveness | >65dB at 10GHz Frequencies | Contact Resistance | < 5mOhm (Initial State) |
| Insulation Resistance | > 5000 MegaOhm (Under 500V DC) | Coupling Mechanism | Triple-Start Threaded / Bayonet Lock |
| Shock Resistance | 300g Half-Sine 3ms Pulse | Shell Finish Options | Electroless Nickel / Black Zinc Nickel (RoHS) |
| Insert Arrangement | Conforms to MIL-STD-1560 Layouts | Interfacial Seal | Fluorosilicone Elastomer |
