MILIANKE ZYNQ7000 Series MLK-L2-CZ06-7020 Development Board Dual-core Cortex-A9 Linux OS DDR3L 1GB EMMC 16GB Multi-Interface
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Main Purpose Not Applicable Embedded Yes Outputs and Type Not Applicable Operating System Linux Board Type Evaluation Platform Communication Interface I2C, USB, HDMI, uart, 4G, wifi, AUDIO Mounting Type PCB Type Development Board Core Processor Cortex-A9 Interface / Description Xilinx ZYNQ7020 Series ZYNQ 7000 Mfg. Date Code / Package CLG484 Function Machine vision, High-speed communication […]
Introduction
| Main Purpose | Not Applicable | Embedded | Yes |
| Outputs and Type | Not Applicable | Operating System | Linux |
| Board Type | Evaluation Platform | Communication Interface | I2C, USB, HDMI, uart, 4G, wifi, AUDIO |
| Mounting Type | PCB | Type | Development Board |
| Core Processor | Cortex-A9 | Interface | / |
| Description | Xilinx ZYNQ7020 | Series | ZYNQ 7000 |
| Mfg. Date Code | / | Package | CLG484 |
| Function | Machine vision, High-speed communication | Utilized IC / Part | / |
| Number of A/D Converters | / | Number of Bits | / |
| Sampling Rate (Per Second) | / | Data Interface | / |
| Input Range | / | Amplifier Type | / |
| Output Type | / | Max Output Power x Channels @ Load | / |
| Voltage - Supply | 12V/3A | Power - Output | / |
| Voltage - Output | / | Current - Output | / |
| Voltage - Input | / | Frequency - Switching | / |
| Platform | / | Current - Output / Channel | / |
| Features | / | Channels per IC | / |
| Regulator Type | / | -3db Bandwidth | / |
| Current - Supply (Main IC) | / | Voltage - Supply, Single/Dual (±) | / |
| Sensor Type | / | Sensitivity | / |
| Module/Board Type | / | Maximum Number Of IC's | / |
| Maximum Time | / | Sensing Range | / |
| SOC Model | XC7Z020-1CLG484I/XC7Z020-2CLG484I | Logic Cells | 85K |
| LUTs | 53200 | Block RAM(#36Kb Blocks) | 4.9Mb(140) |
| DSP(DSP slices) | 220 | Flip-flops | 106400 |
| PS DDR | DDR3L 1GB 1066MHZ*32bits | EMMC | 16GB |
| FLASH | 128Mbit QSPI FLASH | PS crystal oscillator | 33.3333MHZ |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
