MLK CA04 100T 200T Artix7 Series AMD Xilinx Artix 7 Core Board XC7A100T XC7A200T 256Mbits FLASH 1GB DDR3L 800Mbps 32bit
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Main Purpose Not Applicable Embedded Not Applicable Outputs and Type Not Applicable Operating System Not Applicable Board Type Evaluation Platform Communication Interface / Mounting Type PCB Type Core Board Core Processor XC7A100T-2FGG676I/XC7A200T-2FBG676I Interface / Description XC7A100T/XC7A200T Series Artix7 Mfg. Date Code / Package 2FGG676I/2FBG676I Function Machine Vision/High Speed Communication Utilized IC / Part / Number […]
Introduction
| Main Purpose | Not Applicable | Embedded | Not Applicable |
| Outputs and Type | Not Applicable | Operating System | Not Applicable |
| Board Type | Evaluation Platform | Communication Interface | / |
| Mounting Type | PCB | Type | Core Board |
| Core Processor | XC7A100T-2FGG676I/XC7A200T-2FBG676I | Interface | / |
| Description | XC7A100T/XC7A200T | Series | Artix7 |
| Mfg. Date Code | / | Package | 2FGG676I/2FBG676I |
| Function | Machine Vision/High Speed Communication | Utilized IC / Part | / |
| Number of A/D Converters | / | Number of Bits | / |
| Sampling Rate (Per Second) | / | Data Interface | / |
| Input Range | / | Amplifier Type | / |
| Output Type | / | Max Output Power x Channels @ Load | / |
| Voltage - Supply | Core 1V@8A current | Power - Output | / |
| Voltage - Output | / | Current - Output | / |
| Voltage - Input | / | Frequency - Switching | / |
| Platform | / | Current - Output / Channel | / |
| Features | / | Channels per IC | / |
| Regulator Type | / | -3db Bandwidth | / |
| Current - Supply (Main IC) | / | Voltage - Supply, Single/Dual (±) | / |
| Sensor Type | / | Sensitivity | / |
| Module/Board Type | / | Maximum Number Of IC's | / |
| Maximum Time | / | Sensing Range | / |
| Logic Cells | 100T:101440/200T:215360 | LUTs | 100T:63400/200T:134600 |
| Block RAM(kb) | 100T:4860/200T:13140 | DSP | 100T:240/200T:740 |
| Flip-flops | 100T:126800/200T:269200 | XADC | 12bit*1 |
| IO-HR | 100T:300/200T:400 | DDR | DDR3L 256MB*16bit*2@800Mbps(2 pieces in total 1GB, 512MB per piece) |
| FLASH | 256Mbits SPI FLASH | Clock input | 100M differential clock, 100M single ended clock |
