OEM Custom Multilayer Printed Circuit Board Assembly Customer Case Study Intelligent Security Pcb
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Number of Layers 2-32 layer Solder Mask Green Type Multilayer pcb Board Thickness 0.2-6mm(0.01-0.24in) Board Size custom pcb Base Material FR-4/CEM-1/CEM-3/Polyimild/PTFE/Rogers Copper Thickness 0.4-2mil(10-50um) Min. Hole Size 0.1mm(4mil)for HDI / 0.15mm(6mil) Min. Line Width 0.075mm/0.075mm(3mil/3mil) Min. Line Spacing 0.003'' Surface Finishing HASL/OSP/Ag/ENIG/ENEPIG/Immersion silver/Tin Non disclosure agreement Yes DFM FAE Support service Yes Printed circuit board […]
Introduction
| Number of Layers | 2-32 layer | Solder Mask | Green |
| Type | Multilayer pcb | Board Thickness | 0.2-6mm(0.01-0.24in) |
| Board Size | custom pcb | Base Material | FR-4/CEM-1/CEM-3/Polyimild/PTFE/Rogers |
| Copper Thickness | 0.4-2mil(10-50um) | Min. Hole Size | 0.1mm(4mil)for HDI / 0.15mm(6mil) |
| Min. Line Width | 0.075mm/0.075mm(3mil/3mil) | Min. Line Spacing | 0.003'' |
| Surface Finishing | HASL/OSP/Ag/ENIG/ENEPIG/Immersion silver/Tin | Non disclosure agreement | Yes |
| DFM FAE Support service | Yes | Printed circuit board cleaning service | Yes |
| Lead Free Technology | Yes | Gerber files and BOM List | Required from buyer |
| Free Service | Optimize BOM to Reduce Costs | Available sample quantity | 5 PCS |
| Certificate | IATF 16949, ISO 9001, ISO 13485, ISO 14001, and ISO 45001,UL,CE | Test Service | 100% E-testing |
| Other Service | DIP Assembly/100%E-testing/Box Build Assembly |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
