Optical Module Multilayer Printed Circuit Boards, Gold Finger, High Frequency, Rogers PTFE, Communication PCB Assembly PCBA
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Number of Layers 1-32 layers Type High Frequency PCB Board Thickness 0.2 mm – 5.0 mm(0.01in-0.20in) Board Size Max. : 800 mm X 800 mm Base Material FR4, CEM-3, PTFE, F4B, Aluminum , PI , etc Copper Thickness 0.5 oz – 100 oz Min. Hole Size Laser 0.10 mm Mech 0.20 mm Min. Line Width […]
Introduction
| Number of Layers | 1-32 layers | Type | High Frequency PCB |
| Board Thickness | 0.2 mm - 5.0 mm(0.01in-0.20in) | Board Size | Max. : 800 mm X 800 mm |
| Base Material | FR4, CEM-3, PTFE, F4B, Aluminum , PI , etc | Copper Thickness | 0.5 oz - 100 oz |
| Min. Hole Size | Laser 0.10 mm Mech 0.20 mm | Min. Line Width | 3 mil (0.075 mm) |
| Min. Line Spacing | 3 mil (0.075 mm) | Surface Finishing | ENIG, HASL, OSP, Carbon Ink, Immersion Tin |
| Product name | Optical Module Circuit Board | Application | Communication PCB PCBA |
| Certificate | ISO9001, RoHS, IATF16949, UL, ISO13485 | Solder Mask Color | Green, Blue, Black, Red, Purple, White, etc |
| Finish Hole Tolerance (PTH) | ±0.05 mm | Finish Hole Tolerance (NPTH) | ±0.025 mm |
| Buried / Blind via | Support | Assembly process | SMT, DIP, THT soldering |
| MOQ | 1 PIECE | On-Time Delivery Rate | 96.5% |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
