Rogers RO4003C High Frequency PCB Board OEM Factory Multilayer RF Circuit Board Fabrication Manufacturing Service
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type High Frequency PCB Base Material Rogers (PTFE / Ceramic-filled / Hydrocarbon) Board Thickness 0.1mm – 3.2mm (Customizable) Copper Thickness 0.5oz-4oz (18μm-140μm), Customizable up to 6oz Min. Hole Size 0.1mm(Mechanical Drilling)/0.075mm(Laser Microvia) Min. Line Width 0.075mm (3mil), HDI down to 0.05mm (2mil) Min. Line Spacing 0.075mm (3mil), HDI down to 0.05mm (2mil) Surface Finishing ENIG […]
Introduction
| Type | High Frequency PCB | Base Material | Rogers (PTFE / Ceramic-filled / Hydrocarbon) |
| Board Thickness | 0.1mm - 3.2mm (Customizable) | Copper Thickness | 0.5oz-4oz (18μm-140μm), Customizable up to 6oz |
| Min. Hole Size | 0.1mm(Mechanical Drilling)/0.075mm(Laser Microvia) | Min. Line Width | 0.075mm (3mil), HDI down to 0.05mm (2mil) |
| Min. Line Spacing | 0.075mm (3mil), HDI down to 0.05mm (2mil) | Surface Finishing | ENIG / OSP / HASL / Hard Gold / ENEPIG |
| Board Size | OEM / ODM / Customized | Application | 5G / RF Microwave / Automotive Radar / Aerospace / Satellite |
| Rogers Material Series | RO4000 Series / RO3000 Series / RT/duroid Series | Frequency Range | Up to 77GHz / mmWave Compatible |
| Via Technology | Blind Via / Buried Via / Any-Layer HDI / Laser Microvia | Service Type | One-Stop Fabrication / Turnkey OEM / Quick Turn Prototype |
| DFM Support | Free DFM Check / 24H Engineering Feedback | Lead Time | Prototype 3-5 Days / Mass Production 7-15 Days |
| Quality Standard | IPC Class 3 / 100% E-Test / AOI Inspection | Hybrid Stack-up | Rogers + FR4 Hybrid / Mixed Dielectric |
| Sample Policy | Sample Available / MOQ 1 PCS / Low MOQ Accepted |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
