Smart Automotive PCB Solutions IATF16949 for Automotive Industry High Performance Automotive Electronics Double Sided PCB
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Material FR-4 Functional Application Automotive Body Control/ Door Control Unit Type electronic board Base Material FR-4 High-Tg Board Thickness 1.6mm(0.06in) Copper Thickness 1 oz Min. Hole Size ≥0.3mm(≥0.01in) Min. Line Width ≥0.15mm(≥0.01in) Min. Line Spacing ≥0.15mm(≥0.01in) Surface Finishing ENIG Board Size 200mm*160mm(7.87in*6.30in) Layers 4 Layers Certificate ISO 9001/ISO 13485/TATF 16949 Assembly Process SMT+THT(Automotive MCU, Relays, […]
Introduction
| Material | FR-4 | Functional Application | Automotive Body Control/ Door Control Unit |
| Type | electronic board | Base Material | FR-4 High-Tg |
| Board Thickness | 1.6mm(0.06in) | Copper Thickness | 1 oz |
| Min. Hole Size | ≥0.3mm(≥0.01in) | Min. Line Width | ≥0.15mm(≥0.01in) |
| Min. Line Spacing | ≥0.15mm(≥0.01in) | Surface Finishing | ENIG |
| Board Size | 200mm*160mm(7.87in*6.30in) | Layers | 4 Layers |
| Certificate | ISO 9001/ISO 13485/TATF 16949 | Assembly Process | SMT+THT(Automotive MCU, Relays, Driver ICs, Auto Connectors) |
| Application | Electric Door Lock & Window Lift Driver Board | Other Service | Conformal coating/ UV glue/Programming Test/DFM/FAE |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
