Smart Energy Meter PCB 4 Layer FR4 Multilayer Board with High TG 170C for IoT Systems
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Material ShengYi (IT-180A) / Isola Functional Application Smart Energy Meter / AMI Systems Type High Precision Rigid PCB / Smart Hardware Board Base Material High TG FR4 (TG170/180) / Halogen-Free Board Thickness 1.2mm / 1.6mm / 2.0mm Copper Thickness 1oz (35um) / 2oz (Heavy Copper for Power Tracks) Min. Hole Size 0.2mm (Mechanical) / 0.15mm […]
Introduction
| Material | ShengYi (IT-180A) / Isola | Functional Application | Smart Energy Meter / AMI Systems |
| Type | High Precision Rigid PCB / Smart Hardware Board | Base Material | High TG FR4 (TG170/180) / Halogen-Free |
| Board Thickness | 1.2mm / 1.6mm / 2.0mm | Copper Thickness | 1oz (35um) / 2oz (Heavy Copper for Power Tracks) |
| Min. Hole Size | 0.2mm (Mechanical) / 0.15mm (High Precision) | Min. Line Width | 0.1mm (4mil) |
| Min. Line Spacing | 0.1mm (4mil) | Surface Finishing | ENIG (Immersion Gold) / HASL Lead-free |
| Board Size | 4 Layers (Multilayer Stack-up) | Base Material TG | High TG 170°C (TG170) |
| Aspect Ratio | 12:1 | Min Drilling Hole Size | 0.3mm (12 mil) Mechanical Drill |
| Hole Wall Copper Thickness | 25um (1 mil) Average | Operating Temperature | -40°Cto +150°C |
| Withstanding Voltage | ≥1000V AC (Layer to Layer) | Thermal Conductivity | ≥2.0 W/m-K (with Metal Core) |
| Impedance Control Tolerance | ±10% Controlled Impedance | Flammability Rating | UL 94V-0 |
| Application Scenarios | EV Motor Controllers Industrial Drives High-Power Inverters |
