Ultra Precision 6 Layer Optical PCB Prototype High Speed Fiber Optic PCBA for Telecom Data Communication Systems
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Material ShengYi / Isola / Rogers / ITEQ Functional Application Fiber Optic Networking / 5G 6G Base Station Type High Speed Optical PCB / Fiber Optic PCBA Base Material Megtron 7 / High TG FR4 (TG180) Board Thickness 0.8mm / 1.0mm / 1.2mm / 1.6mm (Ultra-Thin spec) Copper Thickness 0.5oz (18um) / 1.0oz (35um) Min. […]
Introduction
| Material | ShengYi / Isola / Rogers / ITEQ | Functional Application | Fiber Optic Networking / 5G 6G Base Station |
| Type | High Speed Optical PCB / Fiber Optic PCBA | Base Material | Megtron 7 / High TG FR4 (TG180) |
| Board Thickness | 0.8mm / 1.0mm / 1.2mm / 1.6mm (Ultra-Thin spec) | Copper Thickness | 0.5oz (18um) / 1.0oz (35um) |
| Min. Hole Size | 0.1mm (Laser Microvia) / 0.15mm (Mechanical) | Min. Line Width | 0.05mm (2mil) |
| Min. Line Spacing | 0.05mm (2mil) | Surface Finishing | Immersion Silver (Ag) / ENIG / ENEPIG |
| Board Size | Immersion Silver (Ag) / ENIG / ENEPIG | Impedance Control | ±5% High Precision (Polar SI9000 Verified) |
| Signal Integrity | Optimized for 25Gbps / 56Gbps Data Rates | Acceptance Standard | IPC-A-600 Class 3 / Telcordia GR-468 |
| Inspection Suite | 100% TDR (Time Domain Reflectometry) & AOI | Via Process | 100% Copper-filled Vias (VIPPO) |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
