Xilinx Artix7 Series MLK H12 CA04 100T 200T DDR3L Flash Storage Development Board for High Speed Communication Machine
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Main Purpose Not Applicable Embedded No Outputs and Type Not Applicable Operating System / Board Type Evaluation Platform Communication Interface I2C, uart, SPI, ETH, PCIE Mounting Type PCB Type Development Board Core Processor / Interface / Description Xilinx-Artix7-XC7A100T/200T Series Artix7 Mfg. Date Code / Package BGA676 Function High-speed communication, Machine vision Utilized IC / Part […]
Introduction
| Main Purpose | Not Applicable | Embedded | No |
| Outputs and Type | Not Applicable | Operating System | / |
| Board Type | Evaluation Platform | Communication Interface | I2C, uart, SPI, ETH, PCIE |
| Mounting Type | PCB | Type | Development Board |
| Core Processor | / | Interface | / |
| Description | Xilinx-Artix7-XC7A100T/200T | Series | Artix7 |
| Mfg. Date Code | / | Package | BGA676 |
| Function | High-speed communication, Machine vision | Utilized IC / Part | / |
| Number of A/D Converters | / | Number of Bits | / |
| Sampling Rate (Per Second) | / | Data Interface | / |
| Input Range | / | Amplifier Type | / |
| Output Type | / | Max Output Power x Channels @ Load | / |
| Voltage - Supply | 12V/3A | Power - Output | / |
| Voltage - Output | / | Current - Output | / |
| Voltage - Input | / | Frequency - Switching | / |
| Platform | / | Current - Output / Channel | / |
| Features | / | Channels per IC | / |
| Regulator Type | / | -3db Bandwidth | / |
| Current - Supply (Main IC) | / | Voltage - Supply, Single/Dual (±) | / |
| Sensor Type | / | Sensitivity | / |
| Module/Board Type | / | Maximum Number Of IC's | / |
| Maximum Time | / | Sensing Range | / |
| Model | XC7A100T-2FGG676I;XC7A200T-2FBG676I | Logic Cells | 100T:101440;200T:215360 |
| LUTs | 100T:63400;200T:134600 | Block RAM(Kb) | 100T:4860;200T:13140 |
| DSP | 100T:240;200T:740 | Flip-flops | 100T:126800;200T:269200 |
| DDR3L | 1GB(2*512MB)DDR3L,data bandwidth 800Mbps*32bit | FLASH | 256Mbits SPI FLASH |
| Clock input | 100M differential clock, 100M single-ended clock | Maximum Power Consumption | 8W |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
