ZYNQ 7000 Development Board with Linux OS and High Speed PCIe for Industrial Automation and Signal Processing
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Main Purpose Not Applicable Embedded Yes Outputs and Type Not Applicable Operating System Linux Board Type Evaluation Platform Communication Interface I2C, uart, USB, ETH, PCIE, FEP, FMC, SATA Mounting Type PCB Type Development Board Core Processor Cortex-A9 Interface / Description Xilinx ZYNQ7000 series development boards Series ZYNQ7000 Mfg. Date Code / Package FFG900 Function Medical […]
Introduction
| Main Purpose | Not Applicable | Embedded | Yes |
| Outputs and Type | Not Applicable | Operating System | Linux |
| Board Type | Evaluation Platform | Communication Interface | I2C, uart, USB, ETH, PCIE, FEP, FMC, SATA |
| Mounting Type | PCB | Type | Development Board |
| Core Processor | Cortex-A9 | Interface | / |
| Description | Xilinx ZYNQ7000 series development boards | Series | ZYNQ7000 |
| Mfg. Date Code | / | Package | FFG900 |
| Function | Medical equipment/Industrialautomation | Utilized IC / Part | / |
| Number of A/D Converters | / | Number of Bits | / |
| Sampling Rate (Per Second) | / | Data Interface | / |
| Input Range | / | Amplifier Type | / |
| Output Type | / | Max Output Power x Channels @ Load | / |
| Voltage - Supply | 12V/3A | Power - Output | / |
| Voltage - Output | / | Current - Output | / |
| Voltage - Input | / | Frequency - Switching | / |
| Platform | / | Current - Output / Channel | / |
| Features | / | Channels per IC | / |
| Regulator Type | / | -3db Bandwidth | / |
| Current - Supply (Main IC) | / | Voltage - Supply, Single/Dual (±) | / |
| Sensor Type | / | Sensitivity | / |
| Module/Board Type | / | Maximum Number Of IC's | / |
| Maximum Time | / | Sensing Range | / |
| PS DDR3 | 1GB, with a data bandwidth of up to 1066MHz*32bit | PL DDR3 | 2GB,with a data bandwidth of up to 1600MHz*64bit |
| EMMC | 8GB/16GB | FLASH | 256Mbit QSPI FLASH |
| Ethernet | 1-channel Gigabit Ethernet at PS/PL end | FMC HPC | FMC HPC expansion port (supporting ADJ), 36 pairs of differential IO |
| FEP | FEP*2,48GPIO/24 pairs of differential(supporting ADJ) | PCIE | 1-channel PClE2.0*8 interface |
| SFP+ | 2-channel SFP+,A single lane can support 10.3125Gbps | SATA | 2-channel SATA interface |
Our website currently displays only a selection of our circuit board products. If you have specific requirements or need more detailed information, feel free to contact us. Our experienced team is ready to provide customized solutions tailored to your project needs. Whether it's design optimization, functional integration, or material selection, we are here to support your goals. Let's work together to develop high-quality circuit board solutions that empower your brand.
