Ultra Thin <0.2mm Rigid Flex PCB Prototype Custom High Frequency High Speed Solutions for Medical Implants & Wearable Devices
$1.25-1.85
/pieces
Price varies depending on material, logo, quantity and customization requirements.
Quality You Can Trust
Flexible & Scalable Solutions
Customizable Product Options
Comprehensive Specifications
Your Reliable Business Partner
Category:
Rigid Flex Pcb
Introduction
| Type | High-Frequency/High-Speed PCB Prototype | Base Material | Rogers RO4350B / PTFE / High TG FR4 |
| Board Thickness | 0.2 mm -6.0 mm(0.01in-0.24in) | Copper Thickness | 0.5 oz - 4 oz |
| Min. Hole Size | 0.15 mm (Mechanical)/0.1 mm (Laser) | Min. Line Width | 3mil |
| Min. Line Spacing | 3mil | Surface Finishing | ENIG (Immersion Gold), Immersion Silver, HASL |
| Board Size | custom | Layer Count | Up to 40 layers |
| Surface Roughness Control | HVLP copper: Ra ≤ 0.5um (for minimal signal loss) | Dk / Df | Dk 3.0-10.2 / Df 0.001-0.020 @10GHz (material dependent) |
| Impedance Tolerance | ±5% (TDR tested, 50Ω/100Ω) | Back Drilling Depth Control | ±0.05 mm precision |
| HDI Technology | Laser drilled blind/buried vias, 0.1 mm hole | Via-in-Pad | Resin plugging & copper plated over |
| ENIG Thickness | Au 2-4u" / Ni 120-200u" | Copper Foil Type | HVLP / RTF / VLP (for low loss) |
| Certifications | UL, RoHS, REACH, ISO9001, IATF16949 |
We are a professional manufacturer and supplier, dedicated to maintaining consistent quality and establishing long-term partnerships with clients worldwide.
Our mission is to provide high-quality products and reliable service. We are committed to offering the following advantages:
- Stable production system ensuring consistent quality, dependable supply, and standardized manufacturing management;
- Strict quality control covering material selection, processing, surface finishing, and final packaging;
- Variety of products and specifications to meet diverse project requirements and application scenarios;
- OEM & customization support based on drawings, samples, or specific technical requirements;
- Flexible packaging solutions to ensure safe handling and transportation of products;
- Continuous improvement in products and services to better support customers in different markets.
If you are interested in our products, please feel free to contact us. We look forward to establishing long-term and mutually beneficial cooperation with you.
